Virtuoso ADE Explorer and Assembler S2: ADE Assembler and Multi Test Corner Analysis
Date | Version | Country | Location | |
---|---|---|---|---|
18 Feb 2020 | IC6.1.8 | Germany | Feldkirchen-Munich Germany |
ENROLL |
17 Mar 2020 | IC6.1.8 | France | Velizy-Paris France |
ENROLL |
09 Jun 2020 | IC6.1.8 | France | Velizy-Paris France |
ENROLL |
30 Jun 2020 | IC6.1.8 | Germany | Feldkirchen-Munich Germany |
ENROLL |
Scheduled upon demandOn demand | EXPRESS INTERESTINQUIRE |
Version | Region | |
---|---|---|
IC6.1.8 | North America | ENROLL |
IC6.1.8 | North America | ENROLL |
Other Regions | EXPRESS INTERESTINQUIRE |
Length : 1 day
Digital Badge Available:
Course Description
In this course, you will set up and run simulations for Analog/Mixed-Signal designs using the Virtuoso® ADE Assembler. Using the maestro cellview, you will set up, run and plot the results for multiple tests. You will also examine and manage the simulation history. This course is a part of the Virtuoso ADE Explorer and Assembler series:
- Virtuoso ADE Explorer and Assembler S1: ADE Explorer and Single Test Corner Analysis
- Virtuoso ADE Explorer and Assembler S2: ADE Assembler and Multi Test Corner Analysis
- Virtuoso ADE Explorer and Assembler S3: Sweeping Variables and Simulating Corners
- Virtuoso ADE Explorer and Assembler S4: Monte Carlo Analysis, Real-Time Tuning and Run Plans
Learning Objectives
After completing this course, you will be able to:
- Start the Virtuoso ADE Assembler Environment and set up single and multiple tests in the environment
- Describe and create maestro cellviews
- Use the Spectre® simulator to run simulations on maestro cellviews
- View waveforms in a docked waveform viewer ViVA XL
- Transition between the Assembler and Explorer
- Translate ADE-XL and ADE-L setups to the Assembler
- Set up different types of expressions/signals to be evaluated
- Set specifications on measured values
- View, interpret and operate on results
- Explore the simulation history tree in the maestro view
- Run simulations incrementally
Software Used in This Course
- Virtuoso Schematic Editor L
- Virtuoso ADE Explorer
- Virtuoso ADE Assembler
- Virtuoso Visualization & Analysis XL
- Spectre Classic Simulator
Software Release(s)
IC618ISR1 and SPECTRE181
Modules in this Course
- Maestro Views and the Virtuoso ADE Assembler
- Setting Up a Multiple Test Environment
- Exploring Simulation History
Audience
- Analog/mixed-signal design engineers
Prerequisites
You must have experience with or knowledge of the following:
- Virtuoso Schematic Editor
- Virtuoso ADE Explorer
Or you must have completed the following courses:
- Virtuoso Schematic Editor
- Virtuoso ADE Explorer and Assembler S1: ADE Explorer and Single Test Corner Analysis
