Virtuoso ADE Explorer and Assembler S1: ADE Explorer and Single Test Corner Analysis
Date | Version | Country | Location | |
---|---|---|---|---|
19 Apr 2021 | IC6.1.8ISR11 | Germany | EMEA-Blended-Germany Germany |
ENROLL |
19 Apr 2021 | IC6.1.8ISR11 | United Kingdom Of Great Britain And Northern Ireland | EMEA-Blended-UK United Kingdom Of Great Britain And Northern Ireland |
ENROLL |
01 Jun 2021 | IC6.1.8ISR11 | France | EMEA-Blended-France France |
ENROLL |
Scheduled upon demandOn demand | EXPRESS INTERESTINQUIRE |
Version | Region | |
---|---|---|
IC6.1.8M | Online | ENROLL |
IC6.1.8ISR11 | Online | ENROLL |
IC6.1.8 | Online | ENROLL |
Other Versions | Online | EXPRESS INTERESTINQUIRE |
Length: 1/2 day
Digital Badge Available
Course Description
This course introduces you to the maestro cellview and the Virtuoso® ADE Explorer tool that uses it. In this course, you set up and run simulations on analog designs and use design variables in your setup, sweep system parameters and run simulations on a single testbench, using Spectre® as the simulator, and view results in the ViVA XL waveform viewer.
This course is a part of the Virtuoso ADE Explorer and Assembler series:
- Virtuoso ADE Explorer and Assembler S1: ADE Explorer and Single Test Corner Analysis
- Virtuoso ADE Explorer and Assembler S2: ADE Assembler and Multi Test Corner Analysis
- Virtuoso ADE Explorer and Assembler S3: Sweeping Variables and Simulating Corners
- Virtuoso ADE Explorer and Assembler S4: Monte Carlo Analysis, Real-Time Tuning and Run Plans
Learning Objectives
After completing this course, you will be able to:
- Start the Virtuoso ADE Explorer tool and create maestro cellviews in IC 618
- Set up varied analyses (dc, ac, transient) on a single test
- Work with design variables and device parameters
- Run simulations using the Spectre simulator
- Display simulation results in the Virtuoso Visualization and Analysis (ViVA) XL waveform window
Software Used in This Course
- Virtuoso Schematic Editor L
- Virtuoso ADE Explorer
- Virtuoso ADE Assembler
- Virtuoso Visualization & Analysis XL
- Spectre Classic Simulator
Software Release(s)
IC618ISR1 and SPECTRE181
Modules in this Course
- Introduction to the Virtuoso Design Environment (Optional)
- Introducing the Virtuoso ADE Explorer
- Analog Simulation Setup and Details
Audience
- Analog/Mixed-Signal Design Engineers
Prerequisites
You must have experience with or knowledge of the following:
- Analog/mixed-signal design concepts
- Analyzing design schematics
Related Courses
Please see course learning maps at this link for a visual representation of courses and course relationships. Regional course catalogs may be viewed here.
